Doypack bag packing machine zipper bag filling and packing 70 bags
output packing machine
Product Description
Related products:
bag packaging machine manufacturers
granules bag filling machine
paste filling packing machine
Our company has many years of service experience in food,
pharmaceutical, chemical, edible oil and other industries. We are
providing machines for China's largest dairy company Yili,
Wandashan, Junlebao and other food companies. Our main service team
has many years of working experience in packaging. Our company's
position in the market is providing high quality and high grade
equipments for our customer. Our factory covers an area of 5000
square meters and has more than 80 employees. We have been engaged
in researching and producing packing machines for many years
Easy Computerized Specification change
Big torquemoment of pouch advance
Stable Pouch advance with less deviation
Unique Walking Beam Structure
Accurate positioning with stable operation
Good Rigidity,big load bearing
Long WB moving distance
Specification:
| ITEM | Parameters |
| Min pouch size | 110mm * 120mm |
| Max pouch size | 190mm * 450mm |
| Capacity | 40-70 pouches/min |
| Packing volume | 1000ml(max) |
| Machine size | 4500(L) х 1200 (W) х 1500 (H)mm |
| Machine weight | 2600Kg |
| Nosie data: | <80dB |
| Relative humidity | <85% |
| Power | AC380V,50Hz |
| Inner power | 4.5Kw |
| Air press | 0.5MPa |
| Gas consumption | 0.6M/min |
Application:
Bag Types:
Machine Features:
1. Premade pouch for big volume flat and doypack packaging
2. Equipped with different metering device, it can realize packing
different material such as powder, liquid, granule, sauce , food
etc.
3. Compact design , easy to operate and maintain.
4. Automatic lubrication system
Real Picture in the workshop
Company Information
Our products includes vertical packing machine,horizontal packing machineandpackage production line and automatic liquid filling production line etc.
Packing EXPO
Packaging & Shipping
International stardard wooden box packinage machine
Installation
The initial installation is NOT included with the professional ROTY team member. All installation with the ROTY team must be scheduled at least 4 weeks in advance before actual
trip taken. All necessary connectivity must be ready prior the
service being scheduled.
While ROTY team member arrives at the site for a complete and final
installation, two days training course will be provide to the
customer for operation and maintenance procedure. The initial
installation is provided within 5 working days excluding travel days. The actual installation days may vary,
based on different machine mode and packing lines. Each day of
working hour consist at 8 working hours..
ROTY provide free parts and parts delivery, when manufacture defects
has been detected during normal operation (vulnerable parts not
included) under warranty period.
