RT420L Vertical Pouch Nuts Packaging Machine 500g Nuts Pouch
Packing 1kg Corn Pouch Packing
PICTURE FOR REFERENCE
Packing specification
Rtl-420: the measuring range of a single bag is within 1200mL
2.1 Multilayer composite film of packaging materials
2.2 Packaging products can be packaged with different cutting
devices
2.3 Packaging Speed RTL-420 Packaging speed: 30-60 packs/min
2.4 Packing accuracy ±1%
The characteristics :
High quality packaging and minimal product loss,
Perfect packaging appearance.
Easy upgrade of main machine
Good working environment.
Product feature:
1. Efficient: Bag - making, filling, sealing, cutting, heating,
date / lot number achieved in one time;
2. Intelligent: Packing speed and bag length can be set through the
screen without part changes;
3. Profession: Independent temperature controller with heat balance
enables different packing materials;
4. Characteristic: Automatic stop function, with safe operation and
saving the film;
5. Convenient: Low loss, labor saving, easy for operation and
maintenance;
6. Weighing accuracy 0.2 to 1.0 gram.
Technical parameters:
| Packing speed: | 30-60bag/min |
| Bag-making size : | (L)80-280mm (W)80-200mm |
| Metering range: | 1000mL (maximum) |
| The maximum packaging film | width is 400mm |
| The film thickness : | 0.04-0.09mm |
| Gas consumption: | 0.8 Mps 0.6m3/min |
| Total power/voltage: | 3.0kW 220V 50HZ |
| Dimensions: | L1350mm*W1100mm*H1620mm |
| The weight: | 420kg |
| |
Electrical parts:
| NO. | NAME | | BRAND | FUNCATION | |
| 1 | Servo motor | CHINA | INOVANCE | PULLING | |
| 2 | Temp control | Korea | Autonics | Temp control | |
| 3 | GPG motor | CHINA | TAIBANG | Transport control | |
| 4 | PLC | CHINA | INOVANCE | Program control | |
| 5 | Touch screen | CHINA | INOVANCE | | |
| 6 | Sensor | CHINA | BDL | BAG CHECK | |
Packaging & Shipping
International stardard wooden box packinage machine
Rutian provides professional packaging and logistics services for
you.With rich experience and careful preparation.We ensure that
the machine is delivered to you safely and soundly
